Six Way Grader Blade

• Attaches to a skid steer, track loader, or any other machine that is equipped with the Universal Quick 'Tach mounting system.
• Tool head weighs 455 lbs.  With the Double Cylinder Rotating Base the attachment weighs 888 lbs.
• 104" wide
• Shaft rotates 0°-16° to the operator's left or 0°-90° to the operator's right with the EZ Spot UR Double Cylinder Rotating Base.
• Blade swivels 18° to the left and 18° to the right.
• Can also be attached to an EZ Spot UR Fixed Non-Rotating Base.
• 2" x 6" swivel cylinder has a breakout force of 9,425 lbs.
• Two 2.5" x 12.5" rotation cylinders have a breakout force of 14,726 lbs. each.
• Composed of Grade 50 steel or higher to withstand years of wear and tear.
• Comes complete with hoses, flush faced couplers, spring hose mount, and wiring harness.
• Can be adapted to fit excavators, wheel loaders, telehandlers, and backhoes with a special bolt-on mount.

The EZ Spot UR Grader Blade is ideal for grading gravel roads, driveways, parking lots, ditches, or yards.  The Grader Blade moves 6 ways: up, down, clockwise and counterclockwise on the y-axis, and clockwise and counterclockwise on the x-axis.  The rotation on the y-axis comes from the shaft rotating on the base, which is  0°-16° to the operator's left or 0°-90° to the operator's right on the Double Cylinder Rotating Base.  The rotation on the x-axis comes from the cylinder extending and retracting on the tool head, which is 18° to the left and 18° to the right.  The Grader Blade is 108" wide so you will be able to grade a larger area in less time.  Made out of grade 50 high strength steel, this attachment will last years and years.
